June 2, 2026 - Anatech Electronics offers the industry's largest portfolio of high-performance standard and customized RF and microwave filters and filter-related products for military, commercial, aerospace and defense, and industrial applications up to 40 GHz. Three new models have been added to the product line in June, including a 9660 MHz (COM1 - COM3) cavity bandpass filter, a 2442 MHz waveguide band stop filter, and a 2072.5 MHz / 2250 MHz / 1800 MHz triplexer filter. Custom RF power filter and directional couplers designs can be designed and produced with required connector types when a standard cannot be found, or the requirements are such that a custom approach is necessary.
The AB9660B1143 is a 9660 MHz cavity bandpass filter with a bandwidth of 220 MHz, a maximum passband insertion loss of 1.0 dB, and a minimum passband return loss of 15 dB.
The AE2442WN2223 is a 2442 MHz waveguide band stop filter with a stop band frequency of 2400 to 2485 MHz, and a minimum stop band attenuation of 50 dB. A maximum passband insertion loss of 1.5 dB, and a minimum passband return loss 14 dB at DC to 2370 MHz, and 12 dB at 2515 to 5000 MHz.
The AD1800-2072-2250TR293 is a triplexer with a frequency range of 2025 to 2120 MHz (COM CH1), 2200 to 2300 MHz (COM- CH2), and 1750 to 1850 MHz (COM- CH3). With a maximum insertion loss of 0.8 dB in all channels and a minimum return loss of 17 dB across all channels.
Visit our website at www.anatechelectronics.com About Anatech Electronics Anatech Electronics, Inc. (AEI) specializes in the design and manufacture of standard and custom RF and microwave filters and other passive components and subsystems employed in commercial, industrial, and aerospace and applications. Products are available from an operating frequency range of 10 kHz to 30 GHz and include cavity, ceramic, crystal, LC, and surface acoustic wave (SAW), as well as power combiners/dividers, duplexers and diplexers, directional couplers, terminations, attenuators, circulators, EMI filters, and lightning arrestors. The company's custom products and capabilities are available at www.anatechelectronics.com. Contact: Anatech Electronics, Inc. |
|||||||||||||
 |
|||||||||||||
|
|||||||||||||
9660 MHz Cavity Bandpass
Filter
2442 MHz Waveguide
Band Stop Filter
2072.5 MHz / 2250 MHz
/ 1800 MHz Triplexer
For more information about
these products or to discuss any of your requirements, please contact us at (973) 772-4242
or send an e-mail to
|
||||||||||||||||||||||||||||||||||||
