Plane Angle Conversions

In geometry and trigonometry, an angle (in full, plane angle) is the figure formed by two rays sharing a common endpoint, called the vertex of the angle. The magnitude of the angle is the "amount of rotation" that separates the two rays, and can be measured by considering the length of circular arc swept out when one ray is rotated about the vertex to coincide with the other. Where there is no possibility of confusion, the term "angle" is used interchangeably for both the geometric configuration itself and for its angular magnitude (which is simply a numerical quantity).

The word angle comes from the Latin word angulus, meaning "a corner". The word angulus is a diminutive, of which the primitive form, angus, does not occur in Latin. - Wikipedia

Standard unit = Radian (rad)




  second minute degree radian revolution
1 s (") = 1 1.667 · 10-2 2.778 · 10-4 4.848 · 10-6 7.716 · 10-7
1 min (') = 60 1 1.667 · 10-2 2.909 · 10-4 4.630 · 10-5
1 deg (º) = 3600 60 1 1.745 · 10-2 2.778 · 10-3
1 rad = 2.063 · 105 3438 57.30 1 0.1592
1 rev 1.296 · 106 2.16 · 104 360 6.283 1
