Aaronia Intros 3D DF Antenna from 9 kHz to 40 GHz

Aaronia AG header - RF Cafe

Ideal for broadband real-time spectrum monitoring Aaronia presents the new 360 ° DF Antenna IsoLOG 3D

Strickscheid, Germany - January 14, 2016

Aaronia Intros 3D DF Antenna from 9 kHz to 40 GHz - RF CafeAvailable in different versions the IsoLOG 3D covers a frequency range of 9 kHz to 40 GHz. The array consists of a total number from 16 to 40 directional antennas with horizontal and vertical polarization. Additionally 8 to 16 special LF antennas can be added in order to cover a frequency range starting at 9 kHz. Overall, the antenna can be equipped with up to 64 independent antennas.

The IsoLOG 3D achieves a high sector-resolution of 22.5° without mechanical rotation. The extremely fast tracking speed of up to 1 µs is achieved by use of high-end digital switches, whereby a signal transmission is also possible with up to 100 W per antenna.

The antenna can be operated with any standard spectrum analyzer and is controllable in any software environment, thanks to the included SDK (Ethernet connection).

Thanks to the robust design, the antenna withstands high mechanical stresses (vibration, shock). Further highlight is the extreme useful temperature range of -40° to 60° Celsius.

Designed and manufactured in Germany every IsoLOG 3D represents the highest quality standards. To illustrate this point the guarantee period of the antenna is 10 years.

About Aaronia AG

Aaronia AG is a technology manufacturer based in Strickscheid / Germany. The company was founded in 2003 and mainly produces Spectrum Analyzers which are based on a patented analysing process. In 2004 Aaronia produced and shipped its first Spectrum Analyzer. Today’s purpose of the company is development, trade and sale of measuring equipment, technologies and rights in the field of low and high frequency measurement technology as well as screening/shielding of RF, magnetic and E-fields.

For more information visit www.aaronia.com

Contacts

Aaronia AG
Manuel Pinten (Sales Manager)
Birgit Hontheim (Public relations)
Gewerbegebiet Aaronia AG
DE-54597 Strickscheid
Germany
Phone: +49 (0)6556-93033
Fax: +49 (0)6556-93034
E-Mail: mp@aaronia.de
URL.: www.aaronia.com





Posted January 29, 2016
